ACD Anti-Collision Device for Tower Crane for Sale – TYB Infra Solutions
Tower cranes are widely used on high-rise construction projects, infrastructure developments, industrial plants, warehouses, and large commercial sites. When multiple tower cranes are operating within the same project area, maintaining a safe working distance between cranes becomes extremely important.
An ACD Anti-Collision Device for Tower Crane is designed to help crane operators and site management monitor crane movements and reduce the risk of interference or collision between tower cranes and other defined operating zones.
TYB Infra Solutions offers ACD Anti-Collision Devices for Tower Cranes for sale, suitable for new installations, replacement requirements, crane upgrades, and existing tower crane installations.
Whether you require an anti-collision system for a single tower crane or a multi-crane construction site, TYB Infra Solutions can assist with suitable equipment based on the crane configuration and project requirements.
What is an ACD Anti-Collision Device for Tower Crane?
An Anti-Collision Device (ACD) is an electronic safety system installed on a tower crane to monitor crane movements and provide warnings when the crane approaches another crane, restricted area, or predefined safety limit.
The system can monitor parameters such as:
- Slewing angle
- Trolley position
- Hook height
- Working radius
- Crane position
- Relative distance between cranes
- Defined prohibited zones
- Potential interference between cranes
Depending on the system configuration, the ACD can provide audible and visual warnings to the operator and may also interface with crane control systems to assist in preventing movement into a programmed safety zone.
The purpose is not to replace the crane operator or site safety procedures, but to provide an additional layer of protection during tower crane operations.
Why is an Anti-Collision System Important for Tower Cranes?
Modern construction projects often have limited working space. It is common for two or more tower cranes to operate within overlapping or adjacent working areas.
For example, a large residential project may have several tower cranes working simultaneously on different buildings. Their jib paths can overlap, making crane coordination essential.
Without an appropriate monitoring and warning system, the operator may have difficulty judging the exact position of another crane, particularly when visibility is restricted.
An ACD system can help operators identify approaching interference and take appropriate action.
Key benefits include:
- Improved crane movement monitoring
- Reduced risk of crane-to-crane interference
- Audible and visual operator warnings
- Monitoring of defined working zones
- Better coordination between multiple tower cranes
- Improved site safety management
- Additional protection during complex lifting operations
- Suitable for new and existing tower cranes
ACD Anti-Collision Device for Multiple Tower Cranes
One of the most common applications for an anti-collision system is a construction site where several tower cranes are operating simultaneously.
When tower cranes are installed close to each other, their working radii can overlap. The anti-collision system can be configured to recognize the operating parameters of the cranes and provide warnings when their defined operating areas approach one another.
A properly configured system can help the operator understand the position and movement of nearby cranes and respond before a dangerous situation develops.
The exact configuration depends on the number of cranes, crane geometry, jib length, installation arrangement, site restrictions, and required safety zones.
Main Functions of Tower Crane ACD
A modern tower crane anti-collision system may provide several monitoring functions depending on the model and configuration.
1. Slewing Angle Monitoring
The system monitors the rotation of the tower crane and determines the angular position of the jib.
This information can be used to identify whether the jib is approaching another crane or a programmed restricted area.
2. Trolley Position Monitoring
The trolley position determines the working radius of the load.
By monitoring trolley movement, the system can calculate the position of the hook and load relative to the tower.
3. Height Monitoring
Hook or trolley height can be monitored to assist in identifying possible interference between cranes operating at different levels.
This can be particularly useful when multiple cranes have overlapping working radii but are operating at different elevations.
4. Working Radius Monitoring
The system can monitor the operating radius of the crane and identify when the trolley approaches a programmed limit.
5. Zone Protection
Restricted or prohibited areas can be programmed depending on the requirements of the project.
For example, a crane may need to avoid:
- Existing buildings
- Power lines
- Roads
- Railway corridors
- Property boundaries
- Other cranes
- Temporary structures
- Restricted construction zones
6. Crane-to-Crane Monitoring
When multiple tower cranes are installed on the same site, the anti-collision system can monitor their relative operating positions.
This helps reduce the possibility of crane jibs, counter-jibs, hooks, or loads entering unsafe interference zones.
Tower Crane Anti-Collision System for Sale
TYB Infra Solutions supplies ACD Anti-Collision Devices for Tower Cranes for various tower crane applications.
Our products can be considered for:
New Tower Crane Installation
An ACD can be incorporated during the installation and commissioning of a new tower crane.
Existing Tower Crane Upgrade
Older tower cranes can be upgraded with an anti-collision monitoring system, subject to compatibility and technical assessment.
Replacement of Damaged ACD
If an existing anti-collision device has failed or requires replacement, TYB Infra Solutions can help identify a suitable replacement system based on the existing crane arrangement.
Multi-Crane Construction Sites
For projects operating two, three, four, or more tower cranes, a suitable multi-crane anti-collision configuration can be considered.
Applications of ACD Systems
Tower crane anti-collision systems are commonly considered for:
- High-rise building construction
- Residential projects
- Commercial buildings
- Metro and infrastructure projects
- Industrial construction
- Power projects
- Cement plants
- Steel plants
- Warehouse construction
- Large-scale civil projects
- Infrastructure development sites
The system can be especially useful where tower cranes have overlapping operating zones or where restricted areas need to be defined.
ACD for Tower Crane Safety
Tower crane safety involves more than a single piece of equipment. Safe crane operation requires proper crane installation, commissioning, regular inspection, trained operators, competent supervision, maintenance, and adherence to applicable safety procedures.
An anti-collision device should therefore be considered as an additional safety and monitoring system, rather than a replacement for proper crane operation and site safety practices.
Correct installation and calibration are also important. Sensors and parameters should be configured according to the actual crane and site arrangement.
Suitable for Different Tower Crane Configurations
Tower cranes differ significantly in their design and operating parameters.
Depending on the crane, the system may need to account for:
- Tower height
- Jib length
- Counter-jib configuration
- Maximum working radius
- Trolley travel
- Slewing range
- Hook height
- Crane location
- Adjacent crane locations
- Restricted zones
- Site layout
For this reason, selecting an ACD solely on the basis of crane tonnage is generally not sufficient.
TYB Infra Solutions can assist in understanding the crane configuration and determining the appropriate anti-collision system requirements.
Why Buy ACD from TYB Infra Solutions?
TYB Infra Solutions provides tower crane-related equipment, components, spares, and solutions for construction and infrastructure requirements.
Our focus is on supplying practical equipment for tower crane owners, contractors, rental companies, construction companies, crane service providers, and project sites.
Our support can include:
- Tower crane ACD supply
- Replacement system requirements
- Technical product selection
- Tower crane spare parts
- Crane electrical components
- Safety-related crane equipment
- Installation-related assistance
- After-sales support
We understand that every construction site has different requirements. Therefore, the correct ACD configuration should be selected according to the crane model and site conditions.
How to Select the Right ACD for Your Tower Crane
Before purchasing an anti-collision system, it is recommended to provide the basic details of the crane and project.
Useful information includes:
- Tower crane make
- Tower crane model
- Jib length
- Maximum lifting capacity
- Maximum working radius
- Crane height
- Number of tower cranes at the site
- Distance between cranes
- Crane layout or site drawing
- Existing ACD details, if replacing an old system
Photos of the existing control panel, sensors, display unit, and crane configuration can also help in identifying the required equipment.
New ACD or Replacement ACD?
If your tower crane already has an anti-collision device but the system is malfunctioning, replacement may be required.
Common issues reported with older systems can include:
- Display failure
- Sensor malfunction
- Communication problems
- Incorrect angle indication
- Incorrect trolley position
- Height sensing problems
- Alarm failure
- Damaged wiring
- Faulty control unit
- Power supply issues
Before replacing the complete system, the individual components should be checked by a qualified technician to determine whether the problem is related to the sensor, wiring, power supply, display, controller, or communication system.
TYB Infra Solutions can help with the supply of replacement ACD equipment based on the available crane and system information.
ACD Anti-Collision Device Price
The price of an ACD Anti-Collision Device for a tower crane depends on the type of system, number of cranes, required sensors, communication arrangement, display configuration, and installation requirements.
A single-crane system and a multi-crane anti-collision system may have significantly different configurations and costs.
For this reason, TYB Infra Solutions provides pricing based on the actual requirement.
To receive a quotation, share the following details:
Tower Crane Make + Model + Jib Length + Number of Cranes + Required Quantity
If possible, also send photographs of the existing system or crane control panel.
ACD Anti-Collision Device for Tower Crane – Buy from TYB Infra Solutions
If you are looking for an ACD Anti-Collision Device for Tower Crane, TYB Infra Solutions can assist with product selection and supply.
We cater to requirements from:
- Tower crane owners
- Construction companies
- Infrastructure contractors
- Crane rental companies
- Tower crane erection contractors
- Crane maintenance companies
- Project contractors
- Equipment dealers
- Industrial contractors
Whether you need a new anti-collision system or a replacement for an existing unit, our team can help you identify the appropriate requirement.
Order Your Tower Crane ACD
For ACD requirements, contact TYB Infra Solutions with your tower crane details.
Send us:
Crane Make:
Crane Model:
Jib Length:
Crane Height:
Number of Cranes:
Project Location:
Required Quantity:
You can also send photographs of the crane, existing ACD system, display, sensors, or control panel.
Our team can review the requirement and provide a suitable quotation.
TYB Infra Solutions
Tower Crane Solutions • Sales • Service • Spares
We supply tower crane equipment, components, spare parts, electrical and safety-related systems for construction and infrastructure requirements.
Looking for an ACD Anti-Collision Device for your Tower Crane? Contact TYB Infra Solutions for availability, technical details and quotation.
