Derrick Crane HDC1830-4T for Sale from TYB Infra Solutions
TYB Infra Solutions offers the HDC1830-4T Derrick Crane for sale, a compact 4-ton capacity derrick crane designed for construction and lifting applications where controlled material handling and a compact crane arrangement are required.
As per the manufacturer’s quotation dated 21 August 2026, the HDC1830 Derrick Crane has a maximum load capacity of 4 tons, 18 metre jib length, 4 ton tip load and 270° slewing.
The crane is offered with its main lifting, slewing and luffing mechanisms, VFD controls, electrical control system, wired remote control and standard accessories.
HDC1830-4T Derrick Crane – Key Specifications
| Specification | Details |
|---|---|
| Model | HDC1830 |
| Crane Type | Derrick Crane |
| Maximum Load | 4 Tons |
| Jib Length | 18 Metres |
| Tip Load | 4 Tons |
| Slewing Range | 270° |
| Hoisting Control | VFD Control |
| Slewing Control | VFD Control |
| Luffing Control | VFD Control |
| Power Supply | 415V / 50Hz |
| Cable | 70 Metres |
| Hoisting Wire Rope Capacity | 400 Metres |
| Remote Control | Wired Remote Control |
| Technical Documents | English service manuals |
These specifications are taken from the supplied HDC1830 quotation.
Main Scope of Supply
The HDC1830-4T Derrick Crane is supplied as a complete package covering the major crane systems.
1. 18 Metre Jib
The package includes an 18 metre jib suitable for the specified crane configuration.
2. Tower Column
One complete set of tower column is included.
3. Supporting Poles
The quoted supply includes 2 sets of supporting poles.
4. Slewing Table
A complete set of slewing table is included in the package.
5. Wired Remote Control
The crane includes one set of wired remote control for crane operation.
6. Hoisting Mechanism
The hoisting system is supplied with VFD control.
7. Slewing Mechanism
The slewing mechanism is supplied with VFD control.
8. Luffing Mechanism
The luffing mechanism is supplied with VFD control.
9. Electrical Control System
A complete electrical control system is included. The quotation specifically notes that the industrial regulator is excluded.
10. Standard Accessories
A full set of standard accessories is included.
11. Cable
The quoted package includes 70 metres of cable.
12. Hoisting Wire Rope
The crane is quoted with 400 metres hoisting wire rope capacity.
13. Power Supply
The specified electrical supply is 415V / 50Hz.
14. Technical Documentation
Complete technical documentation is included, with two sets of English-version service manuals for each unit.
Derrick Crane Price
The manufacturer’s quotation dated 21 August 2026 specifies the following reference prices:
| Price Basis | Price |
|---|---|
| FOB Shenzhen | USD 26,600 / unit |
| CIF Nhava Sheva | USD 29,100 / unit |
The above prices are the manufacturer’s quoted prices and should be confirmed with TYB Infra Solutions at the time of order.
Contact TYB Infra Solutions for the current selling price, taxes, inland transportation, installation and project-specific requirements.
Derrick Crane for Construction Projects
A derrick crane can be particularly useful where conventional tower-crane arrangements are not the preferred solution and a compact lifting arrangement is required.
The HDC1830-4T combines:
- 4-ton maximum load
- 18-metre jib
- 270° slewing
- VFD-controlled mechanisms
- Wired remote operation
- Complete electrical control system
- Standard accessories
- 400-metre hoisting wire rope capacity
This makes the crane a practical option to evaluate for suitable construction and lifting projects.
VFD-Controlled Derrick Crane
The HDC1830 package includes VFD control for the hoisting, slewing and luffing mechanisms.
VFD-based control is included as part of the quoted crane configuration and provides the specified control system for the three primary crane movements.
Packing and Delivery
According to the manufacturer’s quotation, the complete crane package is planned to be packed in one 20GP container.
The stated delivery time is 40 days from receipt of the advance payment for the factory to leave the crane.
Payment Terms
The quotation specifies:
30% advance payment by T/T, with the balance payable by T/T before delivery.
Warranty
The quoted warranty is 12 months for the main parts from the date of bill of lading, excluding easy-worn spare parts.
Why Buy the HDC1830 Derrick Crane from TYB Infra Solutions?
TYB Infra Solutions provides tower crane and construction lifting equipment solutions, including crane sales, service and spare parts.
We can assist customers looking for:
- New derrick cranes
- Construction lifting equipment
- Tower crane solutions
- Crane spare parts
- Crane installation support
- Replacement crane components
- Project-specific crane requirements
Our team can coordinate the technical and commercial requirements based on your project.
Buy HDC1830-4T Derrick Crane from TYB Infra Solutions
Looking for a 4-ton derrick crane for sale in India?
The HDC1830-4T with 18-metre jib is available for enquiry through TYB Infra Solutions.
Send us your project requirements, including:
- Required lifting capacity
- Maximum lifting radius
- Required jib length
- Required quantity
- Project location
- Required delivery schedule
We can provide the applicable commercial offer and discuss the crane configuration for your project.
